4 STAR DGF 0020 IP65

• General
  • Cable length: 0.2 m (20 cm)
  • Cable sheath: PVC (Special soft compound)
  • Cable diameter: 6,5 mm
  • Color: Black
  • Protection class: IP65 (Dust and splash proof)
  • Weight: 45 g
• Connectors
  • Connector 1: XLR 3-pin female (Adam Hall K4CXF3IP65) | Gold plated
  • Connector 2: XLR 5-pin male (Adam Hall K4CXM5IP65) | Gold plated
  • Material: Die-cast zinc with orange sealing elements
• Conductors & Shielding
  • Material: OFC (Oxygen Free Copper)
  • Conductor area: 2 x 0.34 mm²
  • Capacitance/m: 65 pF
  • Wave impedance: 110 Ohm (DMX & AES/EBU)
  • Shielding: Braided copper shield
• Environment/Ambient
  • Operating temperature: -20 - 70 °C

Description of the product

4 STAR DGF 0020 IP65 - Weatherproof DMX adapter (3-pin to 5-pin)

This high-quality adapter from the 4 STAR SERIES is the solution when you need to connect 3-pin DMX equipment to a 5-pin system in demanding outdoor environments. With a length of 20 cm and IP65 rating, safe operation is guaranteed even in rain, moisture and dusty conditions.

The adapter is constructed with Adam Hall's professional 110-ohm DMX cable, which has double OFC conductors and a tight braided copper shield for optimal signal transmission without interference. The special soft PVC jacket ensures that the adapter remains extremely flexible even at lower temperatures.

Equipped with IP65-rated XLR connectors with gold-plated contact surfaces, the risk of corrosion in humid environments is minimized. This makes it the obvious choice for professional lighting technicians working with outdoor events, festivals and permanent installations where different DMX standards meet.
