4 STAR DHM 0020 IP65

• General
  • Cable length: 0.2 m (20 cm)
  • Cable sheath: PVC (Special soft compound)
  • Cable diameter: 6,5 mm
  • Color: Black
  • Protection class: IP65 (Dust and splash proof)
  • Weight: 45 g
• Connectors
  • Connector 1: XLR 5-pin female (Adam Hall K4CXF5IP65) | Gold plated
  • Connector 2: XLR 3-pin male (Adam Hall K4CXM3IP65) | Gold plated
  • Material: Die-cast zinc with orange sealing elements
• Conductors & Shielding
  • Material: OFC (Oxygen Free Copper)
  • Conductor area: 2 x 0.34 mm²
  • Capacitance/m: 65 pF
  • Wave impedance: 110 Ohm (DMX & AES/EBU)
  • Shielding: Braided copper shield
• Environment/Ambient
  • Operating temperature: -20 - 70 °C

Description of the product

4 STAR DHM 0020 IP65 - Weatherproof DMX adapter (5-pin to 3-pin)

This high-quality adapter from the 4 STAR SERIES is the solution when you need to send the signal from a 5-pin system to a luminaire or device with a 3-pin connection in demanding outdoor environments. With a length of 20 cm and full IP65 rating, operational reliability is guaranteed whatever the weather.

Constructed with Adam Hall's professional 110-ohm DMX cable, the adapter offers optimal signal transmission thanks to double OFC conductors and a tightly braided copper shield. The special soft PVC jacket ensures that the adapter maintains its flexibility even in severe cold.

Equipped with IP65-rated XLR connectors with gold-plated contact surfaces, you get a connection that resists corrosion and oxidation over time. It is the ideal tool for festivals, outdoor stages and permanent installations where different DMX generations and standards need to interact seamlessly.
